Fuses
and
circuits
&
Fuse
panel
located
in
the
passenger
compartment
Fuse
panel
Fuse
rating
Circuit
1
20A
.
T
railer
hitch
connector
2
Empty
3
15A
.
Door
locking
4
7.5A
.
Front
wiper
deicer
relay
.
Moonroof
5
7.5A
.
Combination
meter
6
7.5A
.
Remote
control
rear
view
mirrors
.
Seat
heater
relay
7
15A
.
Combination
meter
.
Integrated
unit
8
15A
.
Stop
light
9
20A
.
Mirror
heater
.
Front
wiper
deicer
10
7.5A
.
Power
supply
(battery)
1
1
7.5A
.
T
urn
signal
unit
12
15A
.
Automatic
transmission
unit
.
SRS
airbag
system
(sub)
.
Engine
control
unit
.
Integrated
unit
Specifications
12-5
–
CONTINUED
–
378
