Subaru 2012 Outback - Manual Climate Control; Manual Climate Control System

12
Controls
Manual Climate Control
(if equipped)
1. Temperature Control Dial
Rotate the temperature control dial from
blue for cool, to red for warm.
2. Air Conditioning Button
1SFTTUIFi"$wCVUUPOUPBDUJWBUFUIF 
air conditioning. Press it again to turn off
the air conditioning.
3. Recirculated / Outside Air Button
Press the air inlet selection button to
prevent outside air from being drawn into
the passenger compartment. If the button
is pushed in, press it again to draw outside
BJSJOUPUIFDPNQBSUNFOU5013&7&/5
8*/%4)*&-%'0((*/(%0/05
3&."*/*/5)&3&$*3$6-"5&%.0%&
'03"/&95&/%&%1&3*0%0'5*.&
4. Fan Speed Control Dial
Rotate the fan speed control dial to select
one of four fan speeds.
2
3
4
7
