9.7 StarLink does not start up (Bluetooth connection)
(1) Probable Cause
㻌㻌ͻ CCU abnormality
(2) Wiring Diagram/Connector Diagram
(3)Diagnostic Procedure
1. Check the DTC
ͻ Confirm whether the following DTC have been detected
㻌㻌B2249: Bluetooth Module
㻌㻌No Proceed to step 2
㻌㻌Yes If these DTC are detected, proceed to the countermeasure for each DTC
2. Check the connection
ͻ Confirm whether the Bluetooth cable connector that connect the CCU and CID is
correctly connected or damaged
No ͻ Insert and remove the Bluetooth cable and check again.
ͻ If there is any damage, replace the Bluetooth cable and check again.
Yes Proceed to the next step
ͻ Is the device connected to Bluetooth?
No Connect the mobile phone, and then check again
Yes Proceed to step 3.
To Next Page
