The screen displayed in the category area is comprised of a three-level hierarchical display
and a pop-up display, and the simple GUI designed for good visibility and operability
provides assistance for infotainment system operations.
No. Screen hierarchy Contents
(a)
First layer Home screen
Displays icons as portals for the main categories of the
infotainment system.
(b)
Second layer Category screen
Provides the main screen for the category selected in the Home
screen, and displays setting items and other information in the
category.
(C)
Third layer
Category(details)
Screen
- Displays details or other information for a setting item selected
in the category screen.
- Select "x" (Close) to return to the category screen.
(d)
Pop-up screen
Superimposes a notification or inquiry from the infotainment
system on the corresponding level display according to the
operation content.
