WW-2
WIPER AND WASHER SYSTEM
General Description
1. General Description
A: SPECIFICATION
B: COMPONENT
1. FRONT WIPER
Front wiper motor Input 12 V — 72 W or less
Rear wiper motor Input 12 V — 42 W or less
Front washer motor
Pump type Centrifugal
Input 12 V — 36 W or less
Rear washer motor
Pump type Centrifugal
Input 12 V — 36 W or less
(1) Wiper rubber (4) Wiper rink Tightening torque: N·m (kgf-m, ft-lb)
(2) Wiper blade ASSY (5) Wiper motor T1: 6.0 (0.61, 4.4)
(3) Wiper arm T2: 20 (2.0, 14.5)
WW-00223
T1
T1
T1
T1
T2
T2
(4)
(5)
(3)
(2)
(1)
(3)
(2)
(1)
