ABS-19
ABS (DIAGNOSTICS)
SUBARU SELECT MONITOR
2. READ CURRENT DATA
1) On the «Main Menu» display screen, select the {Each System Check} and press the «YES» key.
2) On the «System Selection Menu» display screen, select the {Brake Control System} and press the «YES»
key.
3) Press the «YES» key after displayed the information of ABS type.
4) On the «Brake Control Diagnosis» display screen, select the {Current Data Display & Save} and press the
«YES» key.
5) On the «Data Display Menu» display screen, select the {Data Display} and press the «YES» key.
6) Using the scroll key, move the display screen up or down until the desired data is shown.
• A list of the support data is shown in the following table.
NOTE:
For detailed operation procedure, refer to the SUBARU SELECT MONITOR OPERATION MANUAL.
3. CLEAR MEMORY MODE
1) On the «Main Menu» display screen, select the {2. Each System Check} and press the «YES» key.
2) On the «System Select Menu» display screen, select {Brake System} and press the «YES» key.
3) Press the «YES» key after displayed the information of engine type.
4) On the «Brake Control Diagnosis» display screen, select the {Clear Memory} and press the «YES» key.
5) When the “Done” and “turn ignition switch OFF” are shown on the display screen, turn the Subaru Select
Monitor and ignition switch to OFF.
NOTE:
For detailed operation procedure, refer to the SUBARU SELECT MONITOR OPERATION MANUAL.
Display screen Contents to be monitored Unit of measure
FR Wheel Speed Wheel speed detected by the Front Right ABS sensor is displayed km/h or MPH
FL Wheel Speed Wheel speed detected by the Front Left ABS sensor is displayed km/h or MPH
RR Wheel Speed Wheel speed detected by the Rear Right ABS sensor is displayed km/h or MPH
RL Wheel Speed Wheel speed detected by the Rear Left ABS sensor is displayed km/h or MPH
Stop Light Switch Stop light switch signal ON or OFF
Stop Light Switch Stop light switch monitor voltage is displayed. V
G sensor output Signal
Refers to vehicle acceleration detecting by the analog G sensor. It
appears on the select monitor display in volts.
V
Valve Relay Signal Valve Relay Signal
ON or OFF
Motor Relay Signal Motor Relay Signal ON or OFF
ABS Signal to TCM ABS operation signal from ABS control module to TCM
ON or OFF
ABS Warning Lamp ON operation of the ABS warning light is displayed. ON or OFF
Motor Relay Monitor Operating condition of the motor relay is displayed. High or Low
Valve Relay Monitor Operating condition of the valve relay is displayed.
ON or OFF
CCM Signal ABS operation signal from ABS control module to TCM
ON or OFF
