ABS-26
ABS (DIAGNOSTICS)
LIST OF DIAGNOSTICS TROUBLE CODE
2. WITH SUBARU SELECT MONITOR
Code Display screen Contents of diagnosis Index No.
—
Communication for ini-
tializing impossible
Select monitor commu-
nication failure
<Ref. to ABS-96, COMMUNICATION FOR INITIALIZING IMPOSSI-
BLE, Diagnostics Chart with Subaru Select Monitor.>
— No trouble code
Although no trouble
code appears on the
select monitor display,
the ABS warning light
remains on.
<Ref. to ABS-100, NO TROUBLE CODE, Diagnostics Chart with
Subaru Select Monitor.>
21
Open or short circuit in
front right ABS sensor
circuit
Open or short circuit in
front right ABS sensor
circuit
<Ref. to ABS-104, TROUBLE CODE 21 — OPEN OR SHORT CIR-
CUIT IN FRONT RIGHT ABS SENSOR CIRCUIT —, Diagnostics
Chart with Subaru Select Monitor.>
22
Front right ABS sensor
abnormal signal
Front right ABS sensor
abnormal signal
<Ref. to ABS-112, TROUBLE CODE 22 — FRONT RIGHT ABNOR-
MAL ABS SENSOR SIGNAL —, Diagnostics Chart with Subaru
Select Monitor.>
23
Open or short circuit in
front left ABS sensor
circuit
Open or short circuit in
front left ABS sensor
circuit
<Ref. to ABS-104, TROUBLE CODE 23 — OPEN OR SHORT CIR-
CUIT IN FRONT LEFT ABS SENSOR CIRCUIT —, Diagnostics
Chart with Subaru Select Monitor.>
24
Front left ABS sensor
abnormal signal
Front left ABS sensor
abnormal signal
<Ref. to ABS-112, TROUBLE CODE 24 — FRONT LEFT ABNOR-
MAL ABS SENSOR SIGNAL —, Diagnostics Chart with Subaru
Select Monitor.>
25
Open or short circuit in
rear right ABS sensor
circuit
Open or short circuit in
rear right ABS sensor
circuit
<Ref. to ABS-104, TROUBLE CODE 25 — OPEN OR SHORT CIR-
CUIT IN REAR RIGHT ABS SENSOR CIRCUIT —, Diagnostics
Chart with Subaru Select Monitor.>
26
Rear right ABS sensor
abnormal signal
Rear right ABS sensor
abnormal signal
<Ref. to ABS-112, TROUBLE CODE 26 — REAR RIGHT ABNOR-
MAL ABS SENSOR SIGNAL —, Diagnostics Chart with Subaru
Select Monitor.>
27
Open or short circuit in
rear left ABS sensor
circuit
Open or short circuit in
rear left ABS sensor
circuit
<Ref. to ABS-106, TROUBLE CODE 27 — OPEN OR SHORT CIR-
CUIT IN REAR LEFT ABS SENSOR CIRCUIT —, Diagnostics Chart
with Subaru Select Monitor.>
28
Rear left ABS sensor
abnormal signal
Rear left ABS sensor
abnormal signal
<Ref. to ABS-114, TROUBLE CODE 28 — REAR LEFT ABNORMAL
ABS SENSOR SIGNAL —, Diagnostics Chart with Subaru Select
Monitor.>
29
Abnormal ABS sensor
signal on any one of
four sensor
Abnormal ABS sensor
signal on any one of
four
<Ref. to ABS-120, TROUBLE CODE 29 — ABNORMAL ABS SEN-
SOR SIGNAL ON ANY ONE OF FOUR SENSOR —, Diagnostics
Chart with Subaru Select Monitor.>
31
Front right inlet valve
malfunction
Front right inlet valve
malfunction
<Ref. to ABS-124, TROUBLE CODE 31 — FRONT RIGHT INLET
VALVE MALFUNCTION —, Diagnostics Chart with Subaru Select
Monitor.>
32
Front right outlet valve
malfunction
Front right outlet valve
malfunction
<Ref. to ABS-129, TROUBLE CODE 32 — FRONT RIGHT OUTLET
VALVE MALFUNCTION —, Diagnostics Chart with Subaru Select
Monitor.>
33
Front left inlet valve
malfunction
Front left inlet valve
malfunction
<Ref. to ABS-124, TROUBLE CODE 33 — FRONT LEFT INLET
VALVE MALFUNCTION —, Diagnostics Chart with Subaru Select
Monitor.>
34
Front left outlet valve
malfunction
Front left outlet valve
malfunction
<Ref. to ABS-129, TROUBLE CODE 34 — FRONT LEFT OUTLET
VALVE MALFUNCTION —, Diagnostics Chart with Subaru Select
Monitor.>
35
Rear right inlet valve
malfunction
Rear right inlet valve
malfunction
<Ref. to ABS-124, TROUBLE CODE 35 — REAR RIGHT INLET
VALVE MALFUNCTION —, Diagnostics Chart with Subaru Select
Monitor.>
36
Rear right outlet valve
malfunction
Rear right outlet valve
malfunction
<Ref. to ABS-129, TROUBLE CODE 36 — REAR RIGHT OUTLET
VALVE MALFUNCTION —, Diagnostics Chart with Subaru Select
Monitor.>
37
Rear left inlet valve
malfunction
Rear left inlet valve
malfunction
<Ref. to ABS-126, TROUBLE CODE 37 — REAR LEFT INLET
VALVE MALFUNCTION —, Diagnostics Chart with Subaru Select
Monitor.>
