ABS-27
ABS (DIAGNOSTICS)
LIST OF DIAGNOSTICS TROUBLE CODE
NOTE:
High
µ
means high friction coefficient against road surface.
38
Rear left outlet valve
malfunction
Rear left outlet valve
malfunction
<Ref. to ABS-130, TROUBLE CODE 38 — REAR LEFT OUTLET
VALVE MALFUNCTION —, Diagnostics Chart with Subaru Select
Monitor.>
41
ABS control module
malfunction
ABS control module
and hydraulic control
unit malfunction
<Ref. to ABS-134, TROUBLE CODE 41 — ABS CONTROL MOD-
ULE MALFUNCTION —, Diagnostics Chart with Subaru Select Mon-
itor.>
42
Power supply voltage
too low
Power supply voltage
too low
<Ref. to ABS-136, TROUBLE CODE 42 — POWER SUPPLY VOLT-
AGE TOO LOW —, Diagnostics Chart with Subaru Select Monitor.>
42
Power supply voltage
too high
Power supply voltage
too high
<Ref. to ABS-138, TROUBLE CODE 42 — POWER SUPPLY VOLT-
AGE TOO HIGH —, Diagnostics Chart with Subaru Select Monitor.>
44
ABS-AT control (Non
Controlled)
ABS-AT control (Non
Controlled)
<Ref. to ABS-142, TROUBLE CODE 44 — ABS-AT CONTROL
(NON CONTROLLED) —, Diagnostics Chart with Subaru Select
Monitor.>
44
ABS-AT control (Con-
trolled)
ABS-AT control (Con-
trolled)
<Ref. to ABS-144, TROUBLE CODE 44 — ABS-AT CONTROL
(CONTROLLED) —, Diagnostics Chart with Subaru Select Monitor.>
51 Valve relay malfunction Valve relay malfunction
<Ref. to ABS-147, TROUBLE CODE 51 — VALVE RELAY MAL-
FUNCTION —, Diagnostics Chart with Subaru Select Monitor.>
51 Valve relay ON failure Valve relay ON failure
<Ref. to ABS-151, TROUBLE CODE 51 — VALVE RELAY ON FAIL-
URE —, Diagnostics Chart with Subaru Select Monitor.>
52
Open circuit in motor
relay circuit
Open circuit in motor
relay circuit
<Ref. to ABS-155, TROUBLE CODE 52 — OPEN CIRCUIT IN
MOTOR RELAY CIRCUIT —, Diagnostics Chart with Subaru Select
Monitor.>
52 Motor relay ON failure Motor relay ON failure
<Ref. to ABS-159, TROUBLE CODE 52 — MOTOR RELAY ON
FAILURE —, Diagnostics Chart with Subaru Select Monitor.>
52 Motor malfunction Motor malfunction
<Ref. to ABS-163, TROUBLE CODE 52 — MOTOR MALFUNCTION
—, Diagnostics Chart with Subaru Select Monitor.>
54
Stop light switch signal
circuit malfunction
Stop light switch signal
circuit malfunction
<Ref. to ABS-166, TROUBLE CODE 54 — STOP LIGHT SWITCH
SIGNAL CIRCUIT MALFUNCTION —, Diagnostics Chart with Sub-
aru Select Monitor.>
56
Open or short circuit in
G sensor circuit
Open or short circuit in
G sensor circuit
<Ref. to ABS-168, TROUBLE CODE 56 — OPEN OR SHORT CIR-
CUIT IN G SENSOR CIRCUIT —, Diagnostics Chart with Subaru
Select Monitor.>
56
Battery short in G sen-
sor circuit
Battery short in G sen-
sor circuit
<Ref. to ABS-172, TROUBLE CODE 56 — BATTERY SHORT IN G
SENSOR CIRCUIT —, Diagnostics Chart with Subaru Select Moni-
tor.>
56
Abnormal G sensor
high
µ
output
Abnormal G sensor
high
µ
output
<Ref. to ABS-178, TROUBLE CODE 56 — ABNORMAL G SENSOR
HIGH M OUTPUT —, Diagnostics Chart with Subaru Select Moni-
tor.>
56
Detection of G sensor
stick
Detection of G sensor
stick
<Ref. to ABS-182, TROUBLE CODE 56 — DETECTION OF G SEN-
SOR STICK —, Diagnostics Chart with Subaru Select Monitor.>
Code Display screen Contents of diagnosis Index No.
