Subaru IMPREZA 2001 - Page 52

ABS-51
ABS (DIAGNOSTICS)
DIAGNOSTICS CHART WITH DIAGNOSIS CONNECTOR
7 CHECK TONE WHEEL RUNOUT.
Measure tone wheel runout.
Is the runout less than 0.05
mm (0.0020 in)?
Go to step
8.
Replace tone
wheel. Front:
<Ref. to ABS-20,
Front Tone
Wheel.> Rear:
<Ref. to ABS-21,
Rear Tone
Wheel.>
8 CHECK RESISTANCE OF ABS SENSOR.
1)Turn ignition switch OFF.
2)Disconnect connector from ABS sensor.
3)Measure resistance between ABS sensor
connector terminals.
Terminal
Front RH No. 1 — No. 2:
Front LH No. 1 — No. 2:
Rear RH No. 1 — No. 2:
Rear LH No. 1 — No. 2:
Is the resistance between 1
and 1.5 k
Ω
?
Go to step
9.
Replace ABS sen-
sor. Front: <Ref.
to ABS-14, Front
ABS Sensor.>
Rear: <Ref. to
ABS-17, Rear
ABS Sensor.>
9 CHECK GROUND SHORT OF ABS SENSOR.
Measure resistance between ABS sensor and
chassis ground.
Terminal
Front RH No. 1 — Chassis ground:
Front LH No. 1 — Chassis ground:
Rear RH No. 1 — Chassis ground:
Rear LH No. 1 — Chassis ground:
Is the resistance more than 1
M
Ω
?
Go to step
10.
Replace ABS sen-
sor. Front: <Ref.
to ABS-14, Front
ABS Sensor.>
Rear: <Ref. to
ABS-17, Rear
ABS Sensor.>
10 CHECK HARNESS/CONNECTOR BETWEEN
ABSCM&H/U AND ABS SENSOR.
1)Connect connector to ABS sensor.
2)Disconnect connector from ABSCM&H/U.
3)Measure resistance at ABSCM&H/U connec-
tor terminals.
Connector & terminal
Trouble code 22 / (F49) No. 11 — No. 12:
Trouble code 24 / (F49) No. 9 — No. 10:
Trouble code 26 / (F49) No. 14 — No. 15:
Trouble code 28 / (F49) No. 7 — No. 8:
Is the resistance between 1
and 1.5 k
Ω
?
Go to step
11.
Repair harness/
connector
between
ABSCM&H/U and
ABS sensor.
11 CHECK GROUND SHORT OF HARNESS.
Measure resistance between ABSCM&H/U
connector and chassis ground.
Connector & terminal
Trouble code 22 / (F49) No. 11 — Chassis
ground:
Trouble code 24 / (F49) No. 9 — Chassis
ground:
Trouble code 26 / (F49) No. 14 — Chassis
ground:
Trouble code 28 / (F49) No. 7 — Chassis
ground:
Is the resistance more than 1
M
Ω
?
Go to step
12.
Repair harness/
connector
between
ABSCM&H/U and
ABS sensor.
12 CHECK GROUND CIRCUIT OF ABSCM&H/U.
Measure resistance between ABSCM&H/U
and chassis ground.
Connector & terminal
(F49) No. 23 — GND:
Is the resistance less than 0.5
Ω
?
Go to step
13.
Repair
ABSCM&H/U
ground harness.
13 CHECK POOR CONTACT IN CONNECTORS.
Is there poor contact in con-
nectors between ABSCM&H/U
and ABS sensor?
Repair connector. Go to step
14.
Step Check Yes No
