Suburban DYNAPACK H Series User Manual

7 Suburban DynaPack H Series Owner's Manual 10/2017 Rev.4
DYNAPACK ACCESSORIES
Part No. Description Unit
1817 Architectural Grille, Aluminum Finish DYPA12AC1A***, DYPA18AC1A*** and DYPA24AC1A***
1818 Architectural Grille, Bronze Finish DYPA12AC1A***, DYPA18AC1A*** and DYPA24AC1A***
1819 Architectural Grille, Aluminum Finish DYPA30AC1A*** and DYPA36AC1A***
1820 Architectural Grille, Bronze Finish DYPA30AC1A*** and DYPA36AC1A***
1741 4" Wall Sleeve Kit DYPA12, DYPA18 and DYPA24
1736 4" Wall Sleeve Kit DYPA30 and DYPA36
1742 6" Wall Sleeve Kit DYPA12, DYPA18 and DYPA24
1737 6" Wall Sleeve Kit DYPA30 and DYPA36
1743 8" Wall Sleeve Kit DYPA12, DYPA18 and DYPA24
1738 8" Wall Sleeve Kit DYPA30 and DYPA36
1744 10" Wall Sleeve Kit DYPA12, DYPA18 and DYPA24
1739 10" Wall Sleeve Kit DYPA30 and DYPA36
1745 12" Wall Sleeve Kit DYPA12, DYPA18 and DYPA24
1740 12" Wall Sleeve Kit DYPA30 and DYPA36
1769 14" Wall Sleeve Kit DYPA 12, DYPA 18, and DYPA 24
1770 14" Wall Sleeve Kit DYPA 30 and DYPA 36
1771 16" Wall Sleeve Kit DYPA 12, DYPA 18, and DYPA 24
1772 16" Wall Sleeve Kit DYPA 30 and DYPA 36
1773 17" Wall Sleeve Kit DYPA 12, DYPA 18, and DYPA 24
1774 17" Wall Sleeve Kit DYPA 30 and DYPA 36
1821 18" Wall Sleeve Kit DYPA 12, DYPA 18, and DYPA 24
1822 18" Wall Sleeve Kit DYPA 30 and DYPA 36
1823 20" Wall Sleeve Kit DYPA 12, DYPA 18, and DYPA 24
1824 20" Wall Sleeve Kit DYPA 30 and DYPA 36
1825 22" Wall Sleeve Kit DYPA 12, DYPA 18, and DYPA 24
1826 22" Wall Sleeve Kit DYPA 30 and DYPA 36
WALL SLEEVE DIMENSIONS (Refer to Figure 7 on the following page)
Part No. A B C D E Unit
1741 5 7/8 6 3/4 28 5/8 28 9/16 28 3/4 DYPA12AC1A***, DYPA18AC1A*** and DYPA24AC1A***
1742 7 7/8 8 3/4 28 5/8 28 9/16 28 3/4 DYPA12AC1A***, DYPA18AC1A*** and DYPA24AC1A***
1743 9 7/8 10 3/4 28 5/8 28 9/16 28 3/4 DYPA12AC1A***, DYPA18AC1A*** and DYPA24AC1A***
1744 11 7/8 12 3/4 28 5/8 28 9/16 28 3/4 DYPA12AC1A***, DYPA18AC1A*** and DYPA24AC1A***
1745 13 7/8 14 3/4 28 5/8 28 9/16 28 3/4 DYPA12AC1A***, DYPA18AC1A*** and DYPA24AC1A***
1769 15 7/8 16 3/4 28 5/8 28 9/16 28 3/4 DYPA12AC1A***, DYPA18AC1A*** and DYPA24AC1A***
1771 17 7/8 18 3/4 28 5/8 28 9/16 28 3/4 DYPA12AC1A***, DYPA18AC1A*** and DYPA24AC1A***
1773 18 7/8 19 3/4 28 5/8 28 9/16 28 3/4 DYPA12AC1A***, DYPA18AC1A*** and DYPA24AC1A***
1821 19 7/8 20 3/4 28 5/8 28 9/16 28 3/4 DYPA12AC1A***, DYPA18AC1A*** and DYPA24AC1A***
1823 21 7/8 22 3/4 28 5/8 28 9/16 28 3/4 DYPA12AC1A***, DYPA18AC1A*** and DYPA24AC1A***
1825 23 7/8 24 3/4 28 5/8 28 9/16 28 3/4 DYPA12AC1A***, DYPA18AC1A*** and DYPA24AC1A***
1736 5 7/8 6 3/4 32 5/8 28 9/16 32 3/4 DYPA30AC1A*** and DYPA36AC1A***
1737 7 7/8 8 3/4 32 5/8 28 9/16 32 3/4 DYPA30AC1A*** and DYPA36AC1A***
1738 9 7/8 10 3/4 32 5/8 28 9/16 32 3/4 DYPA30AC1A*** and DYPA36AC1A***
1739 11 7/8 12 3/4 32 5/8 28 9/16 32 3/4 DYPA30AC1A*** and DYPA36AC1A***
1740 13 7/8 14 3/4 32 5/8 28 9/16 32 3/4 DYPA30AC1A*** and DYPA36AC1A***
1770 15 7/8 16 3/4 32 5/8 28 9/16 32 3/4 DYPA30AC1A*** and DYPA36AC1A***
1772 17 7/8 18 3/4 32 5/8 28 9/16 32 3/4 DYPA30AC1A*** and DYPA36AC1A***
1774 18 7/8 19 3/4 32 5/8 28 9/16 32 3/4 DYPA30AC1A*** and DYPA36AC1A***
1822 19 7/8 20 3/4 32 5/8 28 9/16 32 3/4 DYPA30AC1A*** and DYPA36AC1A***
1824 21 7/8 22 3/4 32 5/8 28 9/16 32 3/4 DYPA30AC1A*** and DYPA36AC1A***
1826 23 7/8 24 3/4 32 5/8 28 9/16 32 3/4 DYPA30AC1A*** and DYPA36AC1A***
WARNING! The unit must be installed with approved wall sleeve and grille accessories for safe operation. Improper installations
could result in property damage, personal injury, or death.
