9 Suburban DynaPack H Series Owner's Manual 10/2017 Rev.4
Figure 9
VENT TERMINAL AIR SUPPLY INLET
X
AREA WHERE TERMINAL IS NOT PERMITTED
A= CLEARANCE ABOVE GRADE,
VERANDA, PORCH, DECK, OR
BALCONY
12 INCHES (30cm)
(SEE NOTE a)
12 INCHES (30cm)
(SEE NOTE a)
J= CLEARANCE TO NONMECHANICAL
AIR SUPPLY INLET TO BUILDING
OR THE COMBUSTION AIR INLET
TO ANY OTHER APPLIANCE.
CANADIAN INSTALLATIONS US INSTALLATIONS
1 2
6 INCHES (15cm) FOR
APPLIANCES £10,000 Btuh (3kw),
12 INCHES (30cm) FOR
APPLIANCES >
10,000 Btuh (3kw)
AND £
100,000 btuh (30kw)
6 INCHES (15cm) FOR APPLIANCES
£10,000 Btuh (3kw),
9 INCHES (23cm) FOR APPLIANCES
>
10,000 Btuh (3kw) AND £ 50,000
Btuh (15kw)
12 INCHES (30CM) FOR
APPLIANCES > 50,000 Btuh (15kw)
B= CLEARANCE TO WINDOW OR
DOOR THAT MAY BE OPENED
6 INCHES (15cm) FOR
APPLIANCES £10,000 Btuh (3kw),
12 INCHES (30cm) FOR
APPLIANCES >
10,000 Btuh (3kw)
AND £
100,000 btuh (30kw)
CANADIAN INSTALLATIONS US INSTALLATIONS
1 2
6 INCHES (15cm) FOR APPLIANCES £10,000 Btuh (3kw),
9 INCHES (23cm) FOR APPLIANCES >
10,000 Btuh (3kw) AND £ 50,000
btuh (15kw)
12 INCHES (30CM) FOR APPLIANCES >
50,000 Btuh (15kw)
K= CLEARANCE TO A MECHANICAL
AIR SUPPLY INLET
6 FEET (1.83m) 3 FEET (91cm) ABOVE IF WITHIN 10FEET
(3m) HORIZONTALLY
C= CLEARANCE TO WINDOW OR
DOOR THAT MAY BE OPENED
* a * a
L= CLEARANCE ABOVE PAVED
SIDEWALK OR PAVED DRIVEWAY
LOCATIED ON PUBLIC PROPERTY
7 FEET (2.13m)
* a
D= VERTICAL CLEARANCE TO
VENTILATED SOFFIT LOCATED ABOVE THE TERMINAL WITHIN A
HORIZONTAL DISTANCE OF 2 FEET (61cm) FROM THE CENTER LINE
OF THE TERMINAL
* a * a
M= CLEARANCE UNDER VERANDA,
PORCH, DECK, OR BALCONY
12 INCHES (30cm)
* a
E= CLEARANCE TO UNVENTILATED SOFFIT
* a * a
F= CLEARANCE TO OUTSIDE CORNER
* a * a
G= CLEARANCE TO INSIDE CORNER
* a * a
H= CLEARANCE TO EACH SIDE OF
CENTER LINE EXTENDED ABOVE
METER / REGULATOR ASSEMBLY
3 FEET (91cm) WITHIN A HEIGHT 15 FEET
(4.5m) ABOVE THE METER / REGULATOR
ASSEMBLY
* a
I= CLEARANCE TO SERVICE
REGULATOR VENT OUTLET
3 FEET (91cm)
* a
1
IN ACCORDANCE WITH THE CURRENT CSA B149.1, NATURAL GAS AND PROPANE INSTALLATION CODE
2
IN ACCORDANCE WITH THE CURRENT ANSI Z223.1/NFPA 54, NATIONAL FUEL GAS CODE
A VENT SHALL NOT TERMINATE DIRECTL ABOVE A SIDEWALK OR PAVED DRIVEWAY THT IS LOCATED BETWEEN TWO SINGLE
FAMILY DWELLINGS AND SERVES BOTH DWELLINGS PERMITTED ONLY IF VERANDA, PORCH, DECK, OR BALCONY IS FULLY OPEN ON A MINUMUM OF TWO SIDES BENEATH THE FLOOR. FOR CLEARANCES NOT SPECIFIED IN ANSI Z223.1/NFPA 54 OR CSA B149.1, ONE OF THE FOLLOWING SHALL BE INDICATED:
*
A REFERENCE TO THE FOLLOWING FOOTNOTE:
"CLEARANCE IN ACCORDANCE WITH LOCAL INSTALLATION CODES AND THE REQUIREMENTS OF THE GAS SUPPLIER AND MANUFACTURERS INSTALLATION INSTRUCTIONS (SEE MANUAL SUPPLIED WITH APPLIANCE)
a)
OPERABLE
FIXED
CLOSED
FIXED
CLOSED
INSIDE
CORNER DETAIL
G
OPERABLE
A
C
F
B
B
B
B
A
J
B
I
H
M
K
E
D
L
B
