Models 427 and 427R Installation 15
subzero.com
Electrical Requirements
A
115 V AC, 60 Hz, 15 amp circuit breaker and electrical
supply are required. A separate circuit, servicing only this
appliance, is required.
The power supply cord has a 3-prong grounding plug,
which must be plugged into a mating 3-prong grounding-
type wall receptacle. Follow the National Electrical Code
and local codes and ordinances when installing the recep-
tacle. For location of the electrical supply, refer to the
installation specifications illustration on the previous page.
IMPORTANT NOTE: For models 427 and 427R, the elec-
trical outlet must be placed so the grounding prong is to
the right of the thinner blades. The outlet must be flush
with the back wall.
IMPORTANT NOTE: A ground fault circuit interrupter
(GFCI) is not recommended and may cause interruption of
operation.
Before moving the wine storage unit into position,
protect any finished flooring with appropriate
materials.
Do not use an extension cord or two-prong adapter.
Electrical ground is required on this appliance.
HOME ALARM SYSTEM
If a home alarm system is to be used, refer to wiring
connections on page 20. In addition to operating power,
the installer may also be required to supply a home
automation system lead to the unit. This is for a low-
voltage, low-current signal similar to door and window
sensor signals. Common, normally open and normally
closed contact configurations are provided.
Three
1
/4" (6) female spade connectors are located in the
compressor compartment and are accessible behind the
kickplate/grille on models 427 and 427R. A minimum of
36" (914) of lead wire should be provided for each contact,
exiting the back wall near the electrical outlet.
Unpacking and Moving
U
ncrate the unit, remove its wood base and discard the
shipping bolts that hold the wood base to the bottom of
the unit. Remove all packing materials and tape.
IMPORTANT NOTE: Do not discard the kickplate/grille,
anti-tip bracket and hardware. These items will be needed
for the installation.
All roller-assembly wine shelves should be removed to
reduce weight and prevent them from rolling. To remove,
pull the shelf out to its full extension, gently and evenly lift
up on both sides of the front of the shelf and remove.
Reverse the procedure to reinstall the shelf.
Retract the front leveling legs to allow you to move the
unit more easily during installation. You will extend the
leveling legs when the unit is in its final position to reduce
the possibility of the unit tipping forward.
Use an appliance dolly to move the wine storage unit.
Position the dolly at the side of the unit to prevent damage
to finished surfaces.
