Models 424 and 424FS Installation 5
subzero.com
Electrical Requirements
A
115 V AC, 60 Hz, 15 amp circuit breaker and electrical
supply are required. A separate circuit, servicing only this
appliance, is required.
The power supply cord has a 3-prong grounding plug,
which must be plugged into a mating 3-prong grounding-
type wall receptacle. Follow the National Electrical Code
and local codes and ordinances when installing the recep-
tacle. For location of the electrical supply, refer to the
installation specifications illustration on the previous page.
IMPORTANT NOTE: For models 424 and 424FS, the elec-
trical outlet must be placed so the grounding prong is to
the right of the thinner blades. The outlet must be flush
with the back wall.
IMPORTANT NOTE: A ground fault circuit interrupter
(GFCI) is not recommended and may cause interruption of
operation.
HOME ALARM SYSTEM
If a home alarm system is to be used, refer to home alarm
connections on page 9. In addition to operating power, the
installer may also be required to supply a home automa-
tion system lead to the unit. This is for a low-voltage, low-
current signal similar to door and window sensor signals.
Common, normally open and normally closed contact
configurations are provided.
Three
1
/4" (6) female spade connectors are located in the
compressor compartment and are accessible behind the
kickplate on models 424 and 424FS. A minimum of 36"
(914) of lead wire should be provided for each contact,
exiting the back wall near the electrical outlet.
Unpacking and Moving
U
ncrate the unit, remove its wood base and discard the
shipping bolts that hold the wood base to the bottom of
the unit. Remove all packing materials and tape.
IMPORTANT NOTE: Do not discard the kickplate, anti-tip
bracket and hardware. These items will be needed for the
installation.
All roller-assembly wine shelves should be removed to
reduce weight and prevent them from rolling. To remove,
pull the shelf out to its full extension, gently and evenly lift
up on both sides of the front of the shelf and remove.
Reverse the procedure to reinstall the shelf.
Use an appliance dolly to move the wine storage unit.
Position the dolly at the back of the unit to prevent
damage to finished surfaces.
Before moving the wine storage unit in to position,
protect any finished flooring with appropriate mate-
rials and secure the door closed.
Do not use an extension cord or two-prong adapter.
Electrical ground is required on this appliance.
