11
FUNCTIONS 4L
BODYPACK/HEADSET/LAVALIER TRANSMITTERS
1. Condenser Capsule
This high-quality microphone uses a condenser
element to capture clear and detailed audio.
2. Set Button
A/B/C/D channel switching: Press and hold the
set button for 2 seconds to do a loop switch in
order of A/B/C/D channels.
Volume adjustment: The current volume level
will display when the device is turned on. The
number of flashes of the channel indicator when
it is turned on corresponds to its volume level
(6 levels adjustable). Each short press of the set
button changes the volume level (incremental
cycle). The number of flashes of the channel
indicator during volume adjustment corresponds
to the currently set volume level.
3. Channel/Battery & Volume Adjustment Indicator
The transmitter features a channel indicator and
battery low voltage indicator that also doubles
as a volume adjustment indicator. The channel
indicator is illuminated with a blue light for
CH A, red light for CH B, yellow light for
CH C, and green light for CH D, allowing for
easy identification of the active channel. During
volume adjustment, the channel indicator
functions as a volume adjustment indicator,
providing a visual indication of the current volume
level. When the battery is low, the corresponding
channel indicator flashes at a frequency of 0.5
seconds to alert the user.
4. Charging indicator
Illuminates when charging.
5. Power/Function button
Switches the unit on/off.
6. Body-pack Clip
The clip allows you to securely attach the receiver
to clothing or a belt.
7. Antenna
The antenna receives the signal from the revceiver
and helps ensure a strong and stable connection.
8. Type-C charging Port
The Type-C charging port is used to charge the
transmitter’s battery. This is useful if the battery is
low, and you need to charge it before using the
receiver again.
1
2
3
4
5
7
861
