7
FUNCTIONS 2H
HANDHELD TRANSMITTER
1. Power button
This button turns the microphone on and off.
2. Battery Indicator
This function displays the current life of the
microphone’s battery.
3. Signal Indicator
The microphone will display a signal strength
when it is properly connected to the receiver.
4. Frequency Display
This function displays the current frequency the
microphone is transmitting on.
5. Channel A/B Signal Indicator
The microphone will display a signal indicating
which channel (A or B) it is currently transmitting
on.
6. Set Button
This button has two functions:
Switch frequency: Tap the set button to switch
between the designated frequencies.
Channel switch: Press and hold the set button
for 1 second to switch between Channel A and
Channel B.
7. Battery Compartment
Unscrew the base to expose the battery
compartment. Insert 2 x 1.5V AA batteries for use.
1
6
7
3
4
2
5
