8
FUNCTIONS 2L
BODYPACK/HEADSET/LAVALIER TRANSMITTERS
1. Condenser Microphone
This high-quality microphone uses a condenser
element to capture clear and detailed audio.
2. Set Button
This button has two functions: Switch frequency:
Tap the set button to switch between the
designated frequencies. Channel switch: Press
and hold the set button for 1 second to switch
between Channel A and Channel B.
3. Channel Indicator I Battery Low Voltage Indicator
The receiver has two channel indicators. The
blue light indicates Channel A, while the red
light indicates Channel B. The lights will remain
on after the power is turned on and will flash
at a frequency of 0.5 seconds when the battery
voltage is low.
4. Charge Display
Illuminates when charging.
5. Power/Function Button
Switches the unit on/off.
6. Body Back Clip
The clip allows you to securely attach the receiver
to clothing or a belt.
7. Antenna
The antenna transmits the signal to the receiver
and helps ensure a strong and stable connection
8. Type-C charging Port
The Type-C charging port is used to charge the
transmitter’s battery. This is useful if the battery is
low, and you need to charge it before using the
receiver again.
1
2
3
4
5
7
61 8
