6
WIRELESS MICROPHONE
1. GRILL
This protects the microphone from damage. Do
not take the grill off, as there are no user service-
able parts inside.
2. LED
This light flashes once turned on and then will
not light again under normal condition. If the
battery is low, the LED will flash.
3. ON/OFF SWITCH
This has three positions. Off at bottom, mute in
the middle (RF signal is operative but audio is
muted), and on at the top.
4. BATTERY COMPARTMENT
This requires 2 x AA batteries (1.5v each). Do
not use any other kind of battery with this
microphone.
5. BATTERY COVER
To remove, push the top of the door slightly
and slide downwards. Opposite is applicable to
reinsert.
BATT
ON
OFF
1
2
3
4
5
