TECHINCAL FEATURES
Voltage rating As indicated on the unit
Tolerance ± 10%
Breaking power µ x16 (10) A / 250 V~
Maximum recommended loads (N/O):
Incandescent lamps: 3000 W
Fluorescent lamps 1200 VA
Low voltage halogen lamps 2000 VA
Halogens (230 V) 3000 W
Low-consumption lamps 600 VA
Downlights 400 VA
Leds 600 VA
Self-consumption 7.3 VA (1.2 W)
Contact AgSnO
2
switched
Operational accuracy ± 1 s/day at 23 ºC
Variation of accuracy with temp. ± 0.15 s / ºC / 24 h
Running reserve 4 years (without mains supply connection)
Type of action DigiPro: 1B, 1S, 1T, 1U.
Software class and structure Class A
Memory slots 32
Nº of channels DigiPro: 1
Types of operation ON; OFF
PULSE: from 1 to 59 seconds
Operating precision ± 1 s
Operating temperature -10 ºC to +45 ºC
Transport and storage Temp -20 ºC to +60 ºC
Contamination situation 2
Protection degree IP 20 as per EN 60529
Protection class II in proper assembly
Ball test temperature + 75 ºC for 21.2.5
Keypad accesses cover Lockable
Connection By means of needle post for maximum
cable section of 4 mm²
Casing dimensions 2 DIN modules (35 mm)
DIMENSIONS
00/06.2015 A016.17.57127
60
65
45
88
35
