4. PLANNING AND INSTALLATION INSTRUCTIONS
Attentions: The shower has to be installed, rinsed and checked in compliance with the applicable regulations in order
to guarantee proper shower function!
The dimensions of the shower set-up must be individually.
Operating pressure at the control valve:
Max. 1Mpa. Recommended operating pressure: 3 bar pressure.
Hot water temperature: Max 60 degree centigrade (140 Fahrenheit).
5. CONCEALED BOX ASSEMBLY INSTALLATION
5.1 Make a mounting rack (normally use woods as materials) for preparing install the concealed box assembly .the mounting board’s
face should be Min 65mm [2-17/32"] and Max 90mm [3-17/32"] behind the finish wall surface.
