Summer 07600C - Page 11

operation:
to unlock gate: hold-open feature:
Slide locking tab back
to release, lift gate
door open.
testing the installation:
Close the gate.
Make sure the
upper and lower
latches lock
securely.
push!
push!
Push the gate and
extension frames
to check
stability.
1
st
2
nd
11
To activate,
open gate door
at least 90º in
either direction.
