11
Note: If mounting directly
into wood, skip this step.
!
x 4
Mark drill
holes with a
pencil through
the center
of each wall cup.
Mark drill
holes with a
pencil through
the center
of each wall cup.
x4
Place a wall cup over
the center of each circular
outline on the wall.
Place a wall cup over
the center of each circular
outline on the wall.
wall cup/top of stairs installation (continued):
1
st
Drill a 7/32
'
'
pilot hole
into each of the 4
center marks.
Drill a 7/32'' pilot hole
into each of the 4
center marks.
2
nd
Insert wall anchors
into pilot holes.
Insert wall anchors
into pilot holes.
7
12
L
K
