Summer Central Station - Gate Configuration Options

3
gate configurations (choose which best fits your scenario)
1 2
4
(28.5 in - 31.25 in.)
without extension frames
(32 in. - 35.25 in.)
with small extension frame
(34.75 in. - 38 in.)
with medium extension frame
NEVER install three extension frames on the
same side of the gate. If using more than one
extension frame, use one on each side of the gate.
!
Note: This instruction book illustrates installation of gate conguration .
If choosing gate conguration , skip ahead to Step 1, page 6. Otherwise,
follow Step #1, page 5, using the appropriate extension frames that
best t your scenario.
Important: Gate includes a door stop (component ) which prevents the gate
from swinging open in one direction. When installing the gate at the top of stairs,
be sure that the door stop is on the stairway side of the gate so the door cannot
open over the stairs. While the door stop comes assembled on the gate, it can be
removed and installed on either side of the gate frame.
When gate is not used at top of stairs, door stop may be removed to allow gate
door to open in either direction.
I
5
3
6
7
8
(44.75 in. - 48 in.)
with medium and large extension frames
(48.75 in. - 52 in.)
with small, medium and large extension frames
(38 in. - 41.25 in.)
with large extension frame
(38.75 in. - 42 in.)
with small and medium extension frames
(42 in. - 45.25 in.)
with small and large extension frames
WARNING
sm
lg
lg sm med
med
!
sm med sm lg
med lg
1
8
Measure the width of the opening where you intend to
install the gate. Refer to the following illustrations to
determine the correct installation conguration.
Baseboard molding may change which conguration is
appropriate.
