Summer Central Station - Wall Cup Installation

8
With a pencil, trace
the entire outline
of each tension bolt
directly onto the wall.
x 4
Loosen the
lower and upper
tension nuts and
remove gate.
loosen!
loosen!
x 2
x 2
Door stop must be
on stair side of gate.
Gate door must open
away from stairs.
!
At the top of the
landing, position the
gate a minimum of
3-6 inches (8-15cm)
away from the top
step.
IMPORTANT
1
2
You MUST install wall cups to keep gate in place.
Without wall cups, child can push out and escape.
WARNING
wall cup installation
