Summer SuperSeat - Assembly and Use Instructions; Stage 1: Infant Support Seat; Stage 2: Floor Time Activity Seat

COMPONENTS:
ENG
* child restraint straps are
pre-assembled on product.
** chair straps are taped to
the underside of the seat.
activity tray (4 sections)
toys (2)
chair straps** (2)
seat assembly
soft seat
child
restraint
straps*
main seat
ASSEMBLY & USE: MONTAGE ET UTILISATION : ENSAMBLAJE Y USO:
MONTAGEM E UTILIZAÇÃO: MONTAGGIO E UTILIZZO: MONTAGE EN GEBRUIK:
MONTAGE UND VERWENDUNG:
N
K
L
A
E
G H
FD
B
C
M
I
J
PT
ENG
FR
AR
IT
ES
NL
DE
toy bar
SET-UP & USE:
Stage 1: Infant support seat (no assembly necessary)
Unbuckle child restraint straps and place child in seat. Secure buckle and adjust to a snug fit.
NOTE: For larger babies, soft seat can be removed by pulling straps through slots in soft seat.
Stage 2: Floor time activity seat
Step 1: Place the 4 tray sections upside down on the floor (Figure A).
Step 2: Fit the rear tray section to the right tray section and secure with 2 screws. Repeat process
with the left tray section (Figures B & C).
Step 3: Turn tray over and slide into position on the seat track exactly as shown in Figures D & E.
Step 4: Rotate the tray clockwise until the opening in the tray matches the opening in the seat
(Figure F).
Step 5: Slide front tray section onto activity tray by squeezing and releasing front latch to lock into
place (Figure G).
Step 6: Insert rabbit teether and tree spinner toys into the holes in the side of the tray (Figure H).
Insert the ends of the toybar into the holes in the back of the tray (Figure I).
Step 7: Unbuckle child restraint straps and place child in seat. Secure buckle and adjust to a snug fit.
Note: When placing baby in and out of seat, rotate tray so that front tray section is in front of the child.
AR
A
7
. .
.
: •3
15 .
.
)
H.(
) I.(
6:
2: .
)B
C.(
3:
.D
E.
4:)
F.(
5:
)
G.(
3:
.
)J)
.(K .(
.
