4
Attack switch changes the time
(fast, medium, slow) it takes
for the TLA-100A to respond to
input signal.
Release switch adjusts the
time (fast, medium, slow) it
takes for the TLA-100A to
return to unity gain.
Link/In/Bypass switch toggles between
bypass (no compression), in
(compressing) and link mode for
stereo linking with another TLA-100A,
TLA-50, or MPC-100A.
Gain controls the output
level (makeup gain).
Meter switch selects the VU meter to
monitor the output level or gain
reduction taking place.
VU Meter monitors output
level or gain reduction.
Gain reduction determines
the amount of gain
reduction taking place on a
signal.
Power switch.
