Model TLA-50 Tube Leveling Amplifier
11
Applications
Ducking
Send the output of the “lead” program material into the side
chain return after inserting the TLA-50 on the “background”
program material.
Example
Send the output of a vocal mic into the side chain, with the
TLA-50 inserted on the lead guitar track. As the singer uses
the vocal mic, the lead guitar will decrease in amplitude.
To TipTo Ring
Channel
Insert
Vocal Channel Out
Lead Guitar
Channel
Side Chain
Ring
TLA-50
OUTPUTS
CLASS A -TUBE LEVELER
MODEL TLA-50
SUMMIT AUDIO INC.
CARMEL, CA USA
115V 50/60 HZ
100V 50/60 HZ
INPUT
+4 BAL. -10 UNBAL.
LINK
INSERT
SIDE
CHAIN
+4 BAL. -10 UNBAL.
20
WATTS
MAX
FUSE
PUSH
