Electrical Connections
14 Summit Audio, Inc.
Electrical
Connections
Input
Note: The Input
connector accepts
either a 1/4” phone
plug or an XLR
connector.
Unbalanced 1/4” jack Balanced 3-pin XLR
Sleeve - - Ground Pin 1 - - Ground
Tip - - - - (+) Signal Pin 2 - - (+) Signal
Pin 3 - - (-) Signal
Output
Unbalanced 1/4” jack Balanced 3-pin XLR
Sleeve - - Ground Pin 1 - - Ground
Tip - - - - (+) Signal Pin 2 - - (+) Signal
Pin 3 - - (-) Signal
Side Chain
Tip - - - - Signal output to EQ
Ring - - - Signal input (from EQ)
Sleeve- - Ground
Stereo Link
Tip - - - - Signal
Sleeve- - Ground
Use a shielded patch cord with 1/4” plug.
