Specifications
Main Chip Devices
Modulator TI TAS5086
Power Stage TI TAS5342L
Digital Audio Receiver TI DIR9001
Audio Performance
Power output, 4 Ω (10% THD+N) 40W
Power output, 4 Ω (0dBFS) 30W
Power output, 6 Ω (10% THD+N) 27W
Power output, 6 Ω (0dBFS) 21W
Power output, 8 Ω (10% THD+N) 21W
Power output, 8 Ω (0dBFS) 17W
Total hamornic distortion (1kHz, -2.5dBFS) <0.09 %
Dynamic Range, a-weighted 103 dB
Signal-to-noise ratio 103 dB
Channel separation 90 dB
Frequency response, audio range (20Hz - 20kHz) +/-0.5dB
Connectors
(1) 4 pcs 4 mm banana speaker terminals, Red positive, black negative
(2) 1 pc RCA style for digital S/PDIF audio input
(3) 1 pc 2.5 mm (in dia.), 5.5 mm (out dia.) DC type output for Squeezebox®
power supply
(4) Select switch for 5V or 9V power supply output for Squeezebox®
(5) AC power switch
(6) AC power, 8-figure type connector
Physical
AC Power Requirements 85-250Vac
Idle/standby 2W
AC Power Requirements 85-250Vac
Idle/standby - incl. SB Receiver in mute or off state 6W
AC Power Requirements 85-250Vac – Full Power 90W
Shipping weight 0.70 kg
Dimensions (WxHxD) approx. 6" x 6" x 1.5"
