SP50DK Radio Keypad
Factory default setting:
Pin code 1: 1234 Pin code 2: 5678
Learning to receiver:
1. Enter the 4 digit pin number. (default PIN or your new pin if changed)
2. Then press and release the learn button on the receiver and red LED will come on.
3. Then press # and hold for 5 seconds
4. The sequence should be 1,2,3,4 learn, # - the gate should now start to drive.
(This needs to be done without any extended gaps and the ‘#’ button needs to be
held at the end for 5 seconds) you should have the keypad at the gate for this.
Change of the pin code:
1. For code 1 enter 1,2,3,4 then ‘*’ key, or code 2 enter 5,6,7,8 then ‘*’ key.
2. Then enter new code then the ‘*’ key.
3. Then enter new code again then the ‘#’ key.
When buzzer sounds for 1 second the change is complete.
Reset back to factory settings:
If you have forgotten the PIN code, you can to reset the keypad back to factory settings. To
do so, disconnect the battery for 15 seconds. Press and hold the ‘*’ and ‘#’ keys together,
while holding the ‘#’ and ‘*’ reconnect the battery. Then a 1 second buzzer will sound to
confirm reset.
Operation:
1. Enter the 4 digit PIN then press and hold the ‘#’ key for 1-2 seconds, if correct a 1
second beep will sound, If incorrect a 3 shot beep will sound.
2. If PIN is entered incorrect 3 times a 5 second beep will sound and lock the keypad for
30 second.
3. To turn backlight on press the ‘#’ key first.
4. The 1
st
press of any key will turn on the RED power LED.
5. Power LED will turn off if no key is pressed for 10 seconds.
6. If battery is low, After you enter the PIN instead of a 1 second beep it will be 2 long
and 2 short beeps and low battery Green LED will come on.
