sunair RT-9000B - Page 266

Document No. 8128000560
Software Revision – N1B (07 Oct 04)
7-34
RT-9000 B
RT-9000 B Transceiver
Transmit BITE (‘TX-BITE’) – Test Details - Non-Resonant Antenna
Test Result Messages
Test
Order
Module Under
Test
Test
Frequency
(MHz)
No Fault found Fault found
‘COUPLER TUNING’
a.
1.75
‘SYSTEM READY’ ‘SYSTEM FAULT’
b.
2.75
c.
3.75
d.
5.75
e.
7.75
f.
10.75
g.
16.75
1
h.
Antenna Coupler
Tuning Test
25.75
2 Audio PCB
‘AUDIO OK’ ‘AUDIO FAULT’
3 IF PCB
‘IF OK’ ‘IF FAULT’
4 Front End PCB
‘FRONT END OK’ ‘FRONT END FAULT’
5 Power Amplifier Assembly
‘POWER AMPL OK’ ‘POWER AMPL FAULT’
a.
1.75
‘FILTER MODULE OK’
‘FILTER MODULE FAULT’
b.
2.75
c.
3.75
d.
5.75
e.
7.75
f.
10.75
g.
16.75
6
h.
Filter
Module
Assembly
25.75
