Document No. 8128000560
Software Revision – N1B (07 Oct 04)
7-2
RT-9000 B
7.1.3 TECHNICAL SPECIFICATIONS
7.1.3.1 GENERAL
FREQUENCY RANGE: Transmit: 1.6 to 29.99999 MHz
Receive - 100 kHz to 29.99999 MHz
(Transmit and Receive frequencies selectable in 10 Hz steps)
PROGRAMMABLE CHANNELS: 128 Simplex or Half-Duplex channels
FREQUENCY STABILITY: Standard: ± 1 part in 10
6
High Stability Option: ± 1 part in 10
8
Warmup Time: After 1 hour = ± 1 part in 10
7
4 hours = ± 4 parts in 10
8
72 hours = ± 1 part in 10
8
MEMORY RETENTION: Non-Volatile
WEIGHT - Lbs (Kg): 49 lbs (22.3)
CONSTRUCTION: Modular plug-in assemblies
SCAN/SWEEP: Manual or automatic Rate/Dwell programmable
MODES OF OPERATION: USB, LSB, CW, AM equivalent, DATA (with external modems)
RF INPUT/OUTPUT IMPEDANCE: 50-Ohms nominal, unbalanced
BITE (Built-In-Test-Equipment): Fault isolated to Lowest Replaceable Unit (LRU) module, descriptive
readout on front panel and individual module indication
INPUT POWER: 115/230 VAC ± 15%, 50/60 Hz; +26 VDC ± 15%; With both input power types
connected, unit will execute AC/DC Auto Changeover
BFO:
± 1.99 kHz, 10 Hz Resolution
SYNTHESIZER LOCK TIME: 10 ms
T/R SWITCHING TIME: 10 ms
REMOTE INTERFACE: RS232, RS422, and 300-Baud FSK Tone
SIZE - Inches (cm): High
: 5.96” (15.2) X Wide: 17.83” (45.4) X Deep: (See below)
(Rack mounting plane – to - rearward extreme) (Front panel protrusion – controls & handles)
Without optional blower kit: 17.66” (44.9)
With optional blower kit: 19.5” (49.5) 1.56” (4.0)
All rack-mounted installations must provide 1.5” (3.8) minimum additional clearance for air circulation
and cable clearance.
Unit must be continuously energized
to maintain specified Frequenc
Stability performance.
