Sunbeam MX9200 Cafe series - BOWL ASSEMBLY

MX9200 Café Series Planetary MixMaster Issue: A Page 5 of 15
C.12
MAIN SHAFT
1
STAINLESS
STEEL
∮12x118.5mmL
C.13
GEAR SHAFT
1
S45C
∮8x52mmL
CARBON STEEL
OD: Ø8 -0.005
-0.011
g5 size
C.14
INSERT SHAFT
2
S45C
∮4x18mmL
CARBON STEEL
Bottom of PIN
target 159mm ±
0.5mm above
top of BOWL
LOCK
C.15
O-RING
3
SILICON
C.16
ROOF RING A
1
0.5mmT FIBER
PAPER
C.17
ROOF RING B
1
0.5mmT FIBER
PAPER
C.18
GEAR HOUSING
SCREWS
3
CARBON STEEL
M4.0X18.0mmL
C.19
SPEED SENSOR
1
CARBON STEEL
M4.0X18.0mmL
Wires Xmm
long
D.
BOWL_ASM
Spare
D.1
BOWL
BOWL BASE
1
SS
MIRROR
POLISHED
MX92008
