ON1 2 3 4 5 6 7 8 9 10 ON1 ON1
OFF ON
DIP SWITCH SETTINGS
Switch OFF ON
SW1
Used HDMI Input
SW2
Used Rear Camera Input
SW3
Used Front Camera Input
SW4
Used DVB-T (CVBS) Input
SW5
Used DVD (CVBS) Input
SW6
SW7
List of Car Model
SW8
SW9
SW10
7 8 9 10
Model Inch
OFF OFF OFF OFF
GLE (C292), E (W212), CLS (W218),
B (W246), CLA (C117)
7
OFF OFF OFF ON C (W205), GLC (x253), V (W447) 8.4
OFF OFF ON OFF S (W222) 12.25
OFF OFF ON ON C (W205), GLC (X253), V (W447) 7
This interface is upgrading to include car model for NTG5
To Next Page
