U_GO_PL_SUNFIRE_SDG1SDG2 (Rev 18) Page 11
SUNFIRE PARTS IDENTIFICATION
Gas Convection Ovens models SDG-1, SDG-2
BURNER AND GAS LINE COMPONENTS
ITEM PART# DESCRIPTION QTY
CRITICAL
1 1467200 Burner Pan 1
2 1467400 Burner 5
3 1467100 Cross-over Bracket 4
4 1265504 Cross-over Angle (alt p/n: G03065-1-9) 2
5
1265548 Orice Fitting - Natural Gas, 48F 5
1265556 Orice Fitting - Propane Gas, 56F 5
6 1913599
Tail Pipe Assembly, 37-1/2”
Note: Tail Pipe 1302197 is No Longer Available.
1
10A
1758901 Pilot - Electronic, Natural Gas 1 C
1758902 Pilot - Electronic, Propane 1 C
10B 1466100 Flame Sensor 1 C
11 1030024 Female Terminal 4
12 4517368 Cable - Flame Sensor 1
17
1754901 Dual Valve - Natural Gas 1 C
1754902 Dual Valve - Propane 1 C
18 1265585 Manifold Assembly 1
19 1265900 Shuto Valve - Manual, 3/4” NPT 1
22 05259 Street Elbow - 90 deg., Black 1
24 21302 Union 1/2” NPT 1
25 02565 Bushing - Hex, 3/4 x 1/2, Black 2
26 14323 Nipple - .50 NPT, Close, SCH 40, Black 3
28A 2152700
Spark Ignition Module
Note: Item is No Longer Available. Use Kit 4529434 (item 28B).
1 C
28B 4529434
Ignition Module Service Kit
Note: Kit includes an ignition module (part# 4528856) and instructions.
1 C
29 1269899 Transformer - Class 2, 120V-24V 1 C
30 1759101 Pilot Bracket 1
33 1004800 1/2 x 1/8 Bell Reducing Coupling 1
34 1007300 1/8 Steel Pipe Plug (as required) 1
35 1666300 Rajh Adapter 1
36 1028713 Tubing - Aluminum, 1/4” x 13” 1
38 1265300 Heat Deector (Over the Manifold) 1
Burner Package Assemblies
CK4538 Natural Gas Burner Kit Nat ICO
CK4539 Propane Burner Package Assembly
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
