SUNFIRE PARTS IDENTIFICATION
Gas Convection Ovens models SDG-1, SDG-2
OVEN COMPONENTS
ITEM PART# DESCRIPTION QTY
CRITICAL
1 G0295201P Blower Wheel Assembly - Nickle Plated 1
2 1011902 Motor Mount Plate 1
3 1915921 Insulation, Motor Pocket 1
4 1012000 Motor Mount Pocket 1
5 CK1012498 Motor Mount Brace Assembly - Side 2
6 CK1012499 Motor Mount Brace Assembly - Top, Bottom 2
7 1686711 Motor - 3/4 HP 115V 2 Speed 1 C
8 CK1012079 Motor Mount Assembly Service Kit 1 C
9 CK1003095
Motor Assembly Kit - 3/4 HP 115V 2 Speed
Note: See Bulletin B-110-2001. Kit includes items 1, 7, 8, and fasteners.
1 C
10 1025800 Lamp Socket - Porcelain 2
11 1025900 Light Socket Gasket 2
12 1026051 Teon Coated Light Bulb 2
13 9004800 Light Cover - Glass 2
14 1534400 Glass Retainer 2
15 1300900 Vent Cover 1
16 1300901 Vent Slide 1
17 G0290401P Blower Inlet Cover 1
18 1540999 Air Bae 1
19 1533701 Air Bae Spacer 4
20
8005000 1/4 Turn Pin 4
8005100 1/4 Turn Fastener Receptacle 4
21 1541000 Air vane 2
25 1315701 Rack Guide Assembly, Deep 2
26 1012700 Oven Rack 28x28 5
27 1317600 Rack Guide Bracket 4
28 1317601 Rack Guide Holddown Bracket 2
29 CK1015797 Capillary Tube Guard 1
30 1020101 Magnetic Catch 2
31 G0285828 Fire Plate Deep (alt p/n: 1013401) 1
32 1297199 Fire Plate Front Support Welded Assembly 2
33 1265700 Fire Plate Support Angle 2
34 1301600 Base Heat Shield (between item 25 and the Top Combustion Chamber) 1
35 1754701 Center Air Shield 1
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
