U_GO_PL_SUNFIRE_SDG1SDG2 (Rev 18) Page 19
SUNFIRE PARTS IDENTIFICATION
Gas Convection Ovens models SDG-1, SDG-2
MAIN EXTERIOR COMPONENTS
ITEM PART# DESCRIPTION QTY
CRITICAL
1 1300600 Top, SS 1
2 1300503 Left Boday Side Panel, SS 1
3 1300509 Right Body Side Panel, SS (Deep) 1
4A CK1721001 Combustion Chamber Front Assembly 1
4B CK4515638 Combustion Chamber Cover 1
4C CK1721099
Combustion Chamber Assembly
Note: Assembly includes items 4A and 4B.
1
6 1014099 Flue Collector Box Assembly 1
8A CK1753298 Leg Assembly, S/S, 28” 4
8B 1753398 Leg Assembly (Double Deck) 4
9
1301100 Top Front Veneer 1
1302601 Side Top Veneer 2
10 1014710 Main Back 1
11 1015508 Rear Control Panel Section 1
12 1014813 Junction Box Bottom, Deep 1
13 1014809 Light Box Cover 1
15 1032503 Element Hole Patch GG 1
16 1029501 8’ Long Power Supply Cord 1
17A 1029430 3/8” x 30” Flex Conduit 2
17B 1028501 3/8 BX Connector, Straight 4
18A 1236100 1-1/2” Square Foot Insert, Chrome Plated 4
18B 1775102 Caster Insert (Single Deck) 4
18C 1755998 Double Deck Caster Pad SS W/A 4
19A 1027500 4” Swivel Caster without Brake, 3/4” NPT Stem 2
19B 1027501 4” Swivel Caster with Brake, 3/4” NPT Stem 2
19C* 1755999 Leg Base 4
20A 1190100 6” Vertical Draft Diverter for Single Unit 1
20B 1190203 Flue Cap - Single Unit 1
21 1015299 Flue Box Assembly Front 1
22 1015205 Rear Flue Box - Bottom Deck 1
23 1015206 Flue Box Top - Bottom Deck 1
24 1015287 Flue Riser Welded Assembly 1
25A 1190101 8” Vertical Draft Diverter for Double Stacked Units 1
25B 1586798 Flue Hood Top - Double Deck 1
25C 1586799 Flue Hood Box Body - Double Deck 1
26 1302500 Fire Plate/ Support Bracket 1
27 1303200 Rear Securing Plate 2
28 CK1129
Caster Kit - Single Deck
Note: Kit includes items 19A (x2), 19B (x2), and 18B (x4).
1
29 CK1200
Caster Kit - Double Deck
Note: Kit includes items 19A (x2), 19B (x2), and 18D (x4)
1
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
