SUNFIRE PARTS IDENTIFICATION
Gas Convection Ovens models SDG-1, SDG-2
ELECTRONIC CONTROL PANEL COMPONENTS
(IM300 Series - Used FROM March-1999 UP TO March-2003)
ITEM PART# DESCRIPTION QTY
CRITICAL
1 CK1946693
Control Panel Assembly
Note: Assembly includes an overlay (1908517), a control panel SDG IM300
(1946693), and a Fast Control keypad (1911701).
1 C
2 4515632 Main Harness SDG-1 1
3A 1910901 Hi-Limit Bracket 1
3B 1955101 Thermal Disc Cooling Switch 1 C
4 1917099 Relay Board Assembly - 120V 1 C
4A 1916901 Relay Board 1 C
4B 1917199 Transformer 120V to 24V 1 C
4C 1767901 Teon Spacers 4
4D 1916801 Relay Board Assembly Bracket 1
5 1765802 Fluted Knob with Two Set Screws 2
6A 2152700
Spark Ignition Module
Note: Item is No Longer Available. Use Kit 4529434 (item 6B).
1 C
6B 4529434
Ignition Module Service Kit
Note: Kit includes an ignition module (part# 4528856) and instructions.
1 C
7 1269899 Transformer, class 2, 120V-24V 1 C
8 1285700 Mallory Timer - 1Hr, 115V 50/60Hz 1 C
9 1911801 Potentiometer 1 C
11 1905701 Digital Control 1 C
12 1666300 1/4 Space to RAJH Type Adapter 1
13
1842901
Probe
Note: Used UP TO NOV-2000.
1 C
1906002
Probe
Note: Used FROM NOV-2000.
1 C
14* 1807838 Wiring Digram - 115V, IM300, SDG-1
15* 1804723 Harness HTR/IGN SDG-1
16* 1804724 Door Harness SDG-1
17* 1804713 Hi-Limit Harness
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
