g! CONFIGURATION DETAILS
The following table provides settings used in the g! Configurator. Please refer to the g! Configurator Reference Guide for more details.
o “<Select>” Select the appropriate item from the list (or drop-down) in the Configurator.
o “<User Defined>”, etc. Type in the desired name for the item.
Devices Variable Name Setting Comments
Communication Devices Name
<User Defined> (Default: Sunfire)
Type Serial Port Refer to the RS-232 Connection Option Integration note for alternative configurations
Communication Type Sunfire TGR-401, TGP-401
Location <User Defined> (Not Required)
COM Port <Select>
Audio Tuners (Optional) Name
<User Defined> (Default: Sunfire Internal AM/FM Tuner) Optional: Only needed if the tuner will be a visible source in the Viewer interface
Device Type Sunfire TGR/TGP-401 Internal AM/FM Tuner Select the tuner that matches your receiver
Location <User Defined> (Not Required)
COM Device
<Select> (Default: Sunfire)
Audio Tuners (Optional) Name
<User Defined> (Default: Sunfire Internal Sirius Tuner) Optional: Only needed if the tuner will be a visible source in the Viewer interface
Device Type Sunfire TGR-401 Internal Sirius Tuner Select the tuner that matches your receiver
Location <User Defined> (Not Required)
COM Device
<Select> (Default: Sunfire)
<Other RS-232 Sources>
<Other IR Controlled Sources>
<Video Display>
Add the Video Display for the receiver. Refer to the Integration Note for the specific display, or the Generic Video Display Integration Note for an IR controlled display
Other Audio Devices / Interfaces Name <User Defined> Add one Interface for each source that should appear in the Viewer
Template <Select>
Default Device <Select> Select the RS-232 or IR controlled source for this interface
Audio Zone Controllers Name <User Defined> Defaults to the make and model of your receiver, after selecting Device Type
Device Type <Select> Select your model of receiver
Location <User Defined> (Not Required)
COM Device
<Select> (Default: Receiver)
Sources Name <User Defined>
Source Device <Select> Sources must be previously configured in order to allow selection.
Source Icon <Select> This icon appears on the source button in the Viewer Interface
Display Name <User Defined> This text appears on the source button in the Viewer Interface
Zones Edit Zone setting such as Name, Show/Hide sources, Universal Receiver, Displays, Slaves and so on as desired. See g! Reference Guide for full details on zone configuration.
<Interface Tab> Click on the Interface tab in order to hide or show zone tabs on indivdual touchscreens
<Touchscreen Options> Select the touchscreen to modify from the list
Tab Layouts <Select>
Move any unused zone tabs into Available Zones to remove from the viewer
Add any other RS-232 controlled sources. Refer to the Integration Note for each specific source device.
Add IR devices on the Input/Output tab for other IR controlled sources. Refer to the Generic IR Source Integration note.
