Sunforce 60031 - Specifications and Monitoring; Technical Specifications; LED Indicator Functions

SPECIFICATIONS
Technical Specifications
PARAMETERS
UNITS
DATA
ELECTRICAL:
Normal input (solar cell array voltage)
Volt
17~22
Max. input solar cell array voltage
Volt
23
Peak charging current:
Amps
12
Current Consumption when connected 12V Array
(Battery not present)
mA
55 max.
Current Consumption when connected 12V battery
(Array not present)
mA
10 max.
CHARGING CHARACTERISTICS
Max. Bulk charging current
Amps
10
Constant voltage for Lead-acid battery
Volt
14.4 +/-0.4
Float mode voltage
Volt
13.5+/-0.4
LCD METER DISPLAY: (60031 only)
Min. LCD Display Voltage
Volt
6.0 +/-0.4
Max. LCD Display Voltage
Volt
19.0 +/-0.4
PROTECTION:
Over temperature protection starting at (Stop charging)
ºC/°F
>85/>185
Over temperature protection reset at (Restart Charging)
ºC/°F
<65/<149
MECHANICAL
Controller Dimension
mm
125 (L) x 65(W)
Controller overall Height
mm
Approx. 27
Net weight
g
Approx. 300
ENVIRONMENTAL CHARACTERISTIC:
Operation temperature
ºC/°F
-5 to 50 / 23 to 122
Storage temperature
ºC/°F
-10 to70 / 14 to 158
Operation humidity range
0 to 80% RH
MONITORING
LED Indicator
The 3 LEDs indicate charging status. These functions are described below.
Solar Power Indication (POWER LED - red)
ON: Indicates solar panel properly connected and solar power supplied normally.
OFF: No power available or insufficient voltage to active charge controller.
Charging status
CHARGING LED - blue;
“Float/Maintaining” CHARGE COMPLETE LED - green
LED
Status
Charging
Charge Complete
“Float/Maintaining”
Conditions
Bulk
Charge
ON
OFF
Indicates the battery is charging,
power from the solar array passes
unrestricted through to the battery.
