The drill size isΦ12mm and the drilling depth is about 85mm.
Pile-mounted charger installation (optional)
④ Install the upper hanging plate and lower hanging
plate.
② Pile installation(after threading).
③ Install the backplate and the
socket-out.
Pile installation effect digram.
Φ12
M4
1.2+0.1N•m
M4
1.2+0.1N•m
2
3
4
1
① AC line installation.
