10
5. Timely recharging of the battery will help prolong the
battery's life. You must recharge the battery pack when
you notice a drop in the equipment's power.
IMPORTANT! Never allow the battery pack to become fully
discharged as this will cause irreversible damage to the
battery.
6. When charging is complete, remove the battery from the
charger by pulling the push lock buttons and sliding the
battery backward to unlock it from the charger.
Assembly
mWARNING! To avoid serious personal injury, read and
understand all safety instructions provided.
mWARNING! Do not insert battery until assembly is
complete. Failure to comply could result in accidental starting
and possible serious personal injury.
mWARNING! Before performing any maintenance,
make sure battery is removed. Failure to heed this warning
could result in serious personal injury.
Adjust the Wheel Frame
NOTE: The patio cleaner comes with the wheel frame in
storage position. Follow the instructions below to set the wheel
frame in operation position.
1. Loosen the wheel frame knob, and rotate the wheel frame
assembly to the working position. Rotate the wheel frame
knob to lock the assembly (Fig. 4).
Pole Assembly
1. Slide the upper pole into the lower pole assembly. Align
the screw holes (Fig. 5).
2. Insert the bolt from the back of the pole through the
aligned holes in the poles and secure the front end with
the knob (Fig. 5).
NOTE: You may have to carefully move the wiring inside
the tube to one side if it blocks the path of the bolt.
3. Loosen the auxiliary handle knob and set the auxiliary
handle in a comfortable working position. Lock the
auxiliary handle knob securely (Fig. 6).
NOTE: The auxiliary handle can be set to 7 angles in 30º
increments. Select the optimal position based on the
project's need.
Connect to Water Source
The patio cleaner can be connected with spigot by a regular
garden hose with the included garden hose adapter. Follow the
instruction below for a secure connection.
mWARNING! The patio cleaner must only be used with
clean water; use of unltered water containing corrosive
chemicals will damage the patio cleaner.
mWARNING! The intake water temperature must not
exceed 95ºF/35ºC.
Fig. 4
Wheel frame assembly
Wheel frame knob
Fig. 5
Upper pole
Lower pole
Pole knob
Bolt
Fig. 6
Auxiliary
handle
Auxiliary
handle knob
