Know Your Cordless Patio Cleaner
Read the owner’s manual and safety instructions carefully before operating the cordless patio cleaner. Compare the illustration
below to the cordless patio cleaner in order to familiarize yourself with the location of the various controls and adjustments. Save
this manual for future reference.
1. Water ow regulation valve
2. Speed control button
3. Direction control button
4. Auxiliary handle
5. Auxiliary handle knob
6. Upper pole
7. Pole knob
8. Lower pole
9. Wheel frame knob
10. Housing
11. Spray wand (2)
12. Nozzle (2)
13. Rotating brush (2)
14. Brush fastener (2)
15. Wheel (2)
16. Garden hose adapter
17. Wheel frame
18. Battery compartment
19. Garden hose supporter
(with Velcro band)
20. Water inlet adapter
21. On/O switch
22. Safety lock button
1
2
34
5
6
78
9
10
11
12
13
14 15
16
17
18
19
20
21
22
24VBAT-LT
24VBAT-XR
24VCHRG-QC
24VCHRG-DPC
24VBAT
24VBAT-LTE
SOLD SEPARATELY
Battery + Charger options
available at sunjoe.com
