8
Technical Data
Battery Voltage* .................................... 24 V D.C.
Battery Capacity ................................... 4.0 Ah
Battery Charge Time Max ..................... 2 hrs 40 min
Battery Run Time Max .......................... 23 min
Charger Input ........................................ 100 – 240 V AC,
50 – 60 Hz, 50 W
Charger Output ..................................... 25.2 V DC
1400 mA
Motor .................................................... 240 W
Air Flow Max ......................................... 35 CFM (1 m
3
/min)
Peak Horsepower ................................. 4.7 HP
Vacuum Pressure Max .......................... 10 kPa
Suction Power Max (Air Watts) ............. 70 W
Suction Hose Length ............................ 5.9 ft (1.8 m)
Tank Capacity ....................................... 5.3 gal (20 L)
Filtration ................................................ foam lter +
cartridge lter +
paper dust bag
Weight (unit alone) ................................ 11 lbs (5 kg)
Weight (with battery installed) .............. 12.7 lbs (5.8 kg)
*Initial no-load voltage, when fully charged, peaks at 24 volts; nominal voltage
under typical load is 21.6 volts.
Unpacking
Carton Contents
• Cordless wet/dry vacuum
• Suction hose
• Telescopic tube
• Air regulation handle
• Crevice nozzle
• Dust brush
• Utility nozzle
• Foam lter
• Paper dust bag
• Screws (8)
• 24V iON+ lithium-ion battery
• 24V iON+ lithium-ion battery charger
• Manuals + Registration card
1. Carefully remove the cordless wet/dry vacuum and check
to see that all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe
®
+ Sun Joe
®
customer service center at
1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use the wet/dry vacuum.
The packaging is made of recyclable materials. Properly
dispose of these materials in accordance with local
regulations.
IMPORTANT! The equipment and packaging material are not
toys. Do not let children play with plastic bags, foils or small
parts. These items can be swallowed and pose a suocation
risk!
Battery Pack Operation
The equipment is powered by a lithium-ion battery. The battery
pack is completely sealed and maintenance free.
mWARNING! Before rst use, the battery requires about
2 hours 40 minutes charge time to be fully charged. When the
battery is at low capacity, recharge for 2 hours 40 minutes
again before resuming operation.
Battery Charge Level Indicator
The battery pack is equipped with a push button for checking
the charge level. Simply press the push button to read o the
battery charge level from the LEDs of the battery indicator:
• All 3 level monitoring LEDs are lit: Battery charge level
is high.
• 2 level monitoring LEDs are lit: Battery charge level is
decreasing. Stop work as soon as possible.
• 1 level monitoring LED is lit: Battery is at. Stop work
IMMEDIATELY and charge the battery. Otherwise the
battery’s service life will be greatly shortened.
NOTE: If the charge level button does not appear to be working,
connect the battery with the charger and charge as needed.
NOTE: Immediately after using the battery pack, the charge
level button may display a lower charge than it will if checked
a few minutes later. The battery cells “recover” some of their
charge after resting.
Charge level button
The battery is at 30% capacity
and requires charging
The battery is at 60% capacity
and requires charging soon
The battery is at full capacity
Light IndicatorsLights
