5
Know Your Cordless Pruner
Read the owner’s manual and safety instructions carefully before operating cordless pruner. Compare the illustration below to
the cordless pruner in order to familiarize yourself with the location of the various controls and adjustments. Save this manual for
future reference.
1. Blade cover
2. Blade lock knob
3. Machine housing
4. Handle
5. Safety lock button
6. On/O switch
7. LED light (2)
8. Blade lock bolt
9. Removable blade
10. Fixed blade
11. AC charger
12. Charging socket
13. Charging indicator
R
1
2
3
4
5
6
7
The other side
8
9
10
End of the handle
13
12
11
Technical Data
Charger Input 120 V ~ 60 Hz
Charger Output 5.4 V 1.8 A
Battery Voltage* 3.6 V
Battery Capacity 2000 mAh
Battery Type Lithium-ion
Cutting Diameter (Max.) 0.5 in. (1.2 cm)
Cutting Speed ≤ 0.6 s
Cutting times (Max) 750 cuts per charge
(based on 9 mm soft wood cuts)
Charging Time 65 min
Weight 1.4 lbs (0.6 kg)
*Initial no-load voltage, when fully charged, peaks at 4.2 volts; nominal voltage under typical load is 3.6 volts.
