Know Your Fire Pit
Read the owner’s manual and safety rules carefully before using your re pit. Compare the illustration below to the actual unit in
order to familiarize yourself with the location of the various parts and hardware. Save this manual for future reference.
1. M6 ring screw
2. Protective screen
3. M6 ange nut
4. Log grid
5. Fire bowl
6. Screen hook
7. Leg (3)
8. Connecting ring
9. M6 x 8 mm bolt (9)
6
D
2
4
5
8
7
Technical Data
Fire Bowl Diameter 29.5 in. (75 cm)
Fire Bowl Depth 4.9 in. (12.5 cm)
Protective screen Dimensions 25.8 in. x 6.7 in.
(65.5 cm x 17 cm)
Screen Hook Dimensions 24 in. (61 cm)
Log Grid Dimensions 16.5 in. (42 cm)
Temperature Resistance 1,022 ºF (550 ºC)
Weight 12 lbs (5.5 kg)
3
1
9
10
10. M6 nut (3)
3
