TestingthePropaneCylinder
Before connecting the cylinder with the generator, make sure
to test the cylinder for leakage. Follow the instructions below.
1. Make sure the propane cylinder is disconnected from the
propane hose and regulator.
2. Make leakage solution by mixing 1 part liquid dish soap
and 3 parts water.
3. Using a clean paint brush, brush the soapy solution over
areas indicated by arrows in Fig. 13.
4. If bubbles show up, there is a leak. Do not use or move
thepropanecylinder.Contactagassupplierorthere
department!
5. If you see, smell, or hear the hiss of escaping gas from the
propane cylinder:
• Move away from propane cylinder.
• Do not attempt to correct the problem yourself.
• Callyourlocalredepartment.
Connecting/InstallingthePropane
Cylinder
Propaneishighlyammableandmayigniteunexpectedly
when mixed with air. The propane cylinder used with this
generator must meet the following requirements:
• Constructedandmarkedinaccordancewithall
specicationsrequiredbyrelatedlawandregulations.
• Measurements:12in.diameterx18in.tallwith20lb.
maximum capacity, or 12 in. diameter x 23 in. tall with 30 lb.
maximum capacity.
• CylindervalvemusthaveType1connectiondevice
compatible with the connector for the generator.
• Cylindermustbeequippedwithsafetyreliefvalve.
• CylindervalvemusthaveULlistedOverllProtection
Device(OPD).ThisOPDsafetyfeatureisidentiedbya
unique triangular handwheel. Use only propane cylinders
with this type of valve.
• Arrangedforvaporwithdrawalandincludecollartoprotect
propane cylinder valve. Always keep propane cylinder in
upright position during use, transport, or storage.
To install and connect the propane cylinder with the generator,
follow the instructions below.
1. Pull the handle lock pin ring and restore the handle to the
storage position. Remove the cap on the propane inlet,
and connect the propane connecting hose to the propane
inlet. Screw the locking nut on the hose clockwise tightly
with a wrench for a secure connection (Fig. 14).
2. Lower the cylinder bracket completely. Place a propane
cylinder (not included) into the bracket, making sure the
bottom of the cylinder is placed securely in the opening
in the bracket. To secure the cylinder, place the cylinder
strap around the cylinder and connect to the hook on the
generator frame as shown (Fig. 15).
3. Make sure the cylinder valve on the propane cylinder is
turnedclockwisetoitsfulloposition.Holdthepropane
connectinghosermlyandinsertthenippleintothe
cylinder valve (Fig. 16).
NOTE: Nipple must be centered in the cylinder valve.
Fig.13
Fig.14
Cylinder
connecting
hose
Propane inlet
Fig.15
Propane
cylinder
Cylinder strap
Cylinder bracket
Hook(onboth
sides)
