Know Your Garden + Utility Cart
1
2
3
4
8
5
6
910
7
1. Removable front panel
2. Handle tube
3. Side panel (2)
4. Side angle clamp (2)
5. Supporting tube
6. Axle
7. Wheel (2)
8. Supporting strap (2)
9. Front angle clamp
10. Bottom panel
11. M6 x 50 screw (8)
12. M6 x 30 screw (4)
13. M6 x 25 screw (15)
14. Cotter pin (4)
15. Handle knob (8)
16. M6 hex nuts (19)
17. Flat washer #1 (4)
18. Flat washer #2 (50)
19. Lock washer (4)
20. Axle clamp (2)
21. Wrench
Technical Data
Heaping Load Capacity 7 cubic foot
Max Weight Capacity 300 lbs (136 kg)
Cart material Plywood + steel
Wheels 20 in. (50.8 cm) bicycle wheels
Removable Front Panel Yes
Weight 55 lbs (25 kg)
3
EN
11
12
13
14
15
16
17
20
21
18
19
