Sunjoy A103000100 - Step 2: Connect Beams and Hooks; Step 3: Insert Beams into Posts; Step 4: Attach Small Beams

C
L
B
ASSEMBLY INSTRUCTIONS
2. Attach the Big Beam (B) to the Big Connector (C),
attach the Hook (L) to the Big Connector (C).
3. Insert the lower connector tube of the Big Beam (B)
into the upper tube of Post (A1 A2 A3), then put
the Big Canopy (J) on big top, do not fully spread.
4. Attach the lower connector tube of Small beam (D)
to the upper tube of Big beam (B).
4
B
B
B
2
3
A1
A2
A3
F
E
B
4
B
D
