Sunjoy L-GZ798PST-E - Assembly Steps; Step 1: Initial Frame Assembly

Fig.1: Spread the Corner Panel (A) on the ground
Fig.2: Insert Long & Short Cross Beam 2(C&E) into Long & Short Cross Beam 1(B&D),
tighten with
Knob (S).
Fig.3: Insert the assembled Cross Beam (B, C, D, E) into Corner Panel (A)
Hardware Pack 1
Small Canopy
Q 1
Mosquito netting
R 1
Knob
S 12
P00152B06011
P00332B01903
P90804A07001
Part NO. QTY
CS NO. Image
Description
