Fig.1: Spread the Corner Panels (A) on the ground, approximately 10 feet apart
Fig.2: Insert Long Cross Beams (B and C) into each other, tighten with Knobs (S); insert Short Cross Beams
(D and E) into each other, tighten with Knobs (S)
Fig.3: Connect Corner Panels (A) with assembled Cross Beams (B-C and D-E); make sure you aligned beams
properly with rails inside, not outside of the frame
Mosquito netting
R 1
Knob
S 12
Plastic Ring
AA
52
7” Ground Stakes
BB 16
To Next Page
